Honeywell PRO 3000 Pdf User Manuals. View online or download Honeywell PRO 3000 User Manual.

The PW-Series Modular Control System is an advanced access control hardware architecture capable of providing solutions for large enterprise applications. The Intelligent Controller (PW6K1IC, PW3K1IC or PW6K1ICE) provides power and flexibility with its 32-bit architecture, TCP/IP support, flash memory, large local cardholder database, and large reader and I/O module support.

The Intelligent Controller is designed to operate off-line, making access control decisions independently from a PC or other controlling device. It can also be connected to a host computer for system configuration, alarm monitoring and direct control. Connectivity to the host computer is accomplished via direct serial communication (RS232 or RS485), dial-up modem, or TCP/IP network connection. The PW-6000 has Ethernet directly embedded and will support a second Ethernet connection.

The PW6K1IC Intelligent Controllers support any combination of up to 32 I/O or reader boards (16 for the PW3K1IC) to monitor alarm input points, relay output points and access control reader interfaces. By offering a modular design, the system can be tailored to meet a wide range of applications, while optimizing cost and mounting space.

The PW-6000 will support up to 300,000 cards and 50,000 transactions. The PW-6101 will support up to 240,000 cards and 50,000 transactions. The PW-3000 Intelligent Controller accommodates a card database of 7,800 cards and a standard transaction buffer of 5,000 transactions.

The PW-Series access modules have been designed to accommodate various mounting options. Units can be wall mounted in a high density configuration (PW5K2ENC1) when space is limited, a 19' rack configuration (PW5K2ENC2), or in a tile mount configuration (PW5K1ENC3). The PW-6000 controller utilizes a built-in Web server to configure the hardware attributes of the controller.

We used rcs and gmake. Build scripts were written in Perl. Each ran on native Windows.

The PRO3200 professional series family of access control modules is designed for high density installations. Supporting up to 16 readers per enclosure and 32 readers per intelligent controller along with up to 100,000 card capacity provides a combination of small installation footprint and superior cost per door ratio.

The PRO22R1 provides I/O support for one card access reader, while the PRO32R2 supports two card access readers. Both interface with the intelligent control module (PRO32IC). In the event that communication to the intelligent control module is lost, the card access readers can be individually configured to allow entrance based on security needs. This customization allows for a door to be configured as locked, unlocked, or access only via valid facility code.

Honeywell Pro 3000 Installation Manual Pdf

The PRO32OUT interfaces with the intelligent control module (PRO32IC) providing up to 12 or 16, Form C, 12 VDC, 2A relay output controls depending if the board is rack or tile-mounted and power fail and panel tamper when tile mounted. Relays may be used for elevator control, status annunciation and for general facility control, such as door monitoring.

Honeywell Pro 3000 Installation Manual

The PRO32IN interfaces with the intelligent control module (PRO32IC) providing 16 supervised alarm inputs and a dedicated power fail and panel tamper when tile mounted. An analog to digital converter samples the input values and the digitized result is filtered and processed. Filter parameters are configurable for each input point, resulting in the ability to specify a custom End-Of-Line (EOL) resistance value, sensitivity range and timing parameter.

The PRO3200 Series of access modules are designed to accommodate various mounting options. Units can be mounted in a rack configuration (PRO22ENC1, PRO22ENC2 and PRO22ENC5) when space is limited, or in a tile-mount configuration (PRO22ENC3).

• The PRO22ENC1 is a wall-mounted enclosure rack unit
• The PRO22ENC2 is a 19' rack-mounted enclosure rack unit
• The PRO22ENC5 is a rack unit which fits inside a customer’s enclosure
